The GB Locking Systems range of Fire Rated products including solenoid bolts, electric strikes, magnetic locks, shearlocks, trimsets, manual digital locks and door loops.

Description

The GB Locking Systems range of Fire Rated products. Please enquire for more information on any of the below;

GB01 – A1 SERIES HIGH SECURITY FIRE RATED ELECTRO MECHANICAL LOCK

  • Very high resistance against any type of aggression
  • Can open under a side load of up to 500N (depending on installation)
  • 20mm bolt projection with anti saw pin
  • Can be installed vertically or horizontally
  • Used on single action and double action doors
  • Can be used with euro cylinder key override
  • Hardened steel locking components (HRC45)
  • Bolt & door position monitoring

GB02 – FIRE RATED SOLENOID BOLT

  • Operating voltage 12V DC
  • Fail-Safe
  • Auto-relocking timer delay: 0, 3, 6 and 9 seconds

GB03 – FIRE RATED ELECTRIC STRIKE

  • Monitored
  • Operating voltage 12 or 24V DC
  • Fail-Safe
  • 500lb holding force
  • 500lb sideload

GB04 – FIRE RATED ELECTRIC STRIKE

  • Operating voltage 12 or 24V DC
  • Fail-secure
  • Holding force: 1000kg

GB05 – FIRE RATED STRIKE FOR PULLMAN LATCH

  • Completely surface mounted
  • Operating voltage 12 or 24V DC
  • Fail-secure
  • Holding force: 1,500lb

GB06 – FIRE RATED MINI MAGNET

  • Monitored
  • Operating voltage 12-24V DC
  • Holding force up to 600lb (272Kg)
  • Fail-Safe

GB07 – FIRE RATED DOUBLE MINI MAGNET

  • Monitored
  • Operating voltage 12-24V DC
  • Holding force up to 2 x 600lb (272Kg)
  • Fail-Safe

GB08 – FIRE RATED STANDARD MAGNET

  • Monitored
  • Operating voltage 12-24V DC
  • Holding force up to 1200lb (544Kg)
  • Fail-Safe

GB09 – FIRE RATED DOUBLE STANDARD MAGNET

  • Monitored
  • Operating voltage 12-24V DC
  • Holding force up to 2 x 1200lb (544Kg)
  • Fail-Safe

GB10 – FIRE RATED WALL MOUNT DOOR RETAINING MAGNET SURFACE

  • Operating voltage options: 12V DC or 24V DC
  • Up to 80lb (36kg) holding force
  • Over-ride switch

GB11 – FIRE RATED WALL MOUNT DOOR RETAINING MAGNET FLUSH

  • Operating voltage options: 12V DC or 24V DC
  • Up to 70lb (32kg) holding force
  • Over-ride switch

GB12 – FIRE RATED FLOOR MOUNT DOOR RETAINING MAGNET

  • Operating voltage options: 12V DC or 24V DC
  • Up to 80lb (36kg) holding force
  • Over-ride switch

GB13 – FIRE RATED ELECTRIC LOCK

  • Monitored
  • Operating voltage 12V DC (24V DC available)
  • Fail-safe
  • 1500lb holding force
  • 500lb side-load

GB14 – FIRE RATED MORTICE SHEARLOCK

  • Operating voltage 12-24V DC
  • Holding force up to 2,600lb (1,200kg) in shear
  • Locking time delay: 0.5 to 25 seconds

GB15 – FIRE RATED TRIMSET

  • Ability to adjust Daylight Saving Time
  • Ability to update (read/write) to the card
  • Transponder: MIFARE® Classic (13.56Mhz)*
  • Max Users: 64,000
  • Max Doors: 64,000
  • Time zones: 200, each time zone consists of 12 periods

GB16 – FIRE RATED ARMOURED DOOR LOOP

  • 400m, 610mm or 850mm

GB17 – FIRE RATED CONCEALED DOOR LOOP

  • Maximum diameter of wire bundle- 7.5mm
  • Finish- Chrome

GB18 – FIRE RATED MANUAL DIGITAL LOCK

  • Reversible lever handles
  • Hold back facility
  • Additional code tumblers allowing you to use digits twice
